ADM8725 Common Rail System Test Bench, for testing and calibrating of different common rail pumps and injectors, three kinds of output for option, LCD Display

Technical Specifiions:

1. Power: 11Kw,15Kw,18.5Kw

2. Rated Voltage: 220V/380V/415V

3. Rated Voltage: 50/60Hz

4. Cylinders: 6/12

5. Speed Range : 0----5000rpm

6. Temperature Control Range : 42℃, Accuracy:±2℃

7. Fuel supply pressure range: 0----0.4Mpa

8. Feed Volume Measurement Range: 0.1ml----2000ml

9. Return Volume Measurement Range: 1----600L/H

10. Rail pressure: UP TO 2500Bar

11. Cooling capacity: 5000Kal

Main Characteristics:

For testing and calibrating:

1.For the testing of different common rail pumps

BOSCH:CP1,CP2,CP3 pumps

DENSO:HP0,HP3,HP4

DELPHI pumps

2.For the testing of common rail injectors of BOSCH,DENSO,DELPHI.

3.For the testing piezo injectors of BOSCH,DENSO,VDO

Our company have a history over decades of years, owning a skilled and inovative team with advanced knowledge and experience. Our company have got the quality certifie of the ISO9000 and TS16949 system and manage the company as required.

Those ensure the high quality of our products and enable us enjoy a high reputation from our customers. We are authorized to be the OEM producer of many famous manufacturers. Now our products are exported to lots of countries in the world, such as Mid-east, Europe, America, South America and Southeast Asia, etc. In some area, our products even cover over 50% of the market share.

We know that it is the quality and the service which decide our position in the world market. We will spare no effect to meet the request of our customers and provide you the best products with best service and best price.

If you have any question about the products or any problem about the technology, no matter whether you are going to purchasing the Goods, please don't hesitate to contact us. We will be honored to do something for you.
